MS35489-3 - GROMMET, NONMETALLIC
NSN: 5325-00-276-6101, NIIN: 2766101
New Surplus, Sold Per Each
A grommet is a nonmetallic or metallic ring designed to protect wires, cables, or hoses as they pass through holes in panels or surfaces. Made from durable materials like nylon, it prevents abrasion, insulates, and provides a secure fit
Specifications
Grommet Construction Type: Solid
Style: Round
Material: Rubber Synthetic
Flange Thickness: 0.063" Min - 0.125" Max
Groove Outside Diameter: 0.984" Min - 1.016" Max
Groove Width: 0.046" Min - 0.078" Max
Hole Diameter: 0.109" Min - 0.141" Max
Large Flange Outside Diameter: 1.219" Min - 1.281" Max
Overall Height: 0.109" Min - 0.141" Max
Features Provided: Coolant Resistant And Oil Resistant
Part Number Info
Part Number: MS35489-3
Unpunctuated: MS354893
NSN: 5325-00-276-6101
NIIN: 2766101
Potential Alternates: AN931-2-16, 113002ADX, 113002, MILG3036, MS35489-3S, MS35490-3, 12Z12002-1
Replaces Cancelled NSN: 5325-01-091-1320, 5325-00-971-8539
New Surplus: These parts are classified as new and unused, meaning they have not been installed or placed into service. However, they come without traceability or original manufacturer certifications, which might be required for certain high-level regulatory uses. Our company provides its own Certificate of Conformance (CoC) as a statement of assurance that the parts are in good working condition and have been sourced from reliable channels. These are ideal when the focus is on cost-effectiveness without compromising on quality.
Sold Per Each: This item is sold individually, with the price listed for a single unit. Perfect for purchasing the exact quantity needed without the requirement to buy in bulk. For larger quantities, consider reviewing any available bulk pricing options.
Product Testing: Every product is inspected for accuracy, quality, and functionality before shipping to meet our high standards.
Alternate Part Numbers: Due to the nature of ever-evolving part numbering structure, multiple part numbers may meet the same specifications and performance standards. If only an alternate part number is available, we will contact you to confirm compatibility. We strongly recommend consulting the appropriate repair manuals to ensure accuracy before using an alternate part.
