MS3476W10-6P – CONNECTOR, CIRCULAR

Description

MS3476W10-6P – CONNECTOR, CIRCULAR

Specifications

Body Style: Straight Shape, Internal Coupling
Protection: Moisture Proof And Salt Water Resistant And Vibration Proof
Special Features: In Order To Complete The Connector Assembly, The User Must Obtain/Provide The Backshell. Standard Versions May Be Ordered As Nsn 5935-01-179-5430, P/N M85049/52-1-10W For The Straight Style, Or Nsn 5935-01-171-5758, P/N M85049/51-1-10W For The Right Angle Style; Weapon System Essential
Terminal Type: Crimp Single Mating End Single Contact Grouping
Contact Surface: Gold Single Mating End Single Contact Grouping And Nickel Single Mating End Single Contact Grouping
Precious Material: Gold
Shell Material: Aluminum Alloy
Shell Surface Treatment: Cadmium
Overall Diameter: 0.926″ Max
Overall Length: 1.420″ Max
Nominal Thread Length: 0.290″
Thread Class: 2A
Thread Direction: Right-Hand
Thread Quantity Per Inch: 24
Thread Series Designator: Unef
Thread Size: 0.625″
Contact Arrangement Style: 10-6 Single Mating End
Contact Quantity: 6 Single Mating End Single Contact Grouping
Contact Type: Round Pin Single Mating End Single Contact Grouping
Locking Method: Bayonet Latch
Mating End Quantity: 1
Max Ac Voltage: 600.0 Single Mating End Single Contact Grouping
Polarization Method: Keyway Or Multiple Keyway
Shell Type: Solid
Threaded Device Type: Back Shell
Contact Removal: Removable Single Mating End Single Contact Grouping

Part Number: MS3476W10-6P
Unpunctuated: MS3476W106P

The specifications above are for reference only. Verify tolerances and details in the official spec sheets before use.
