204-012-116-003 – MAIN ROTOR SHIELD, ASSEMBLY

Description

204-012-116-003 – MAIN ROTOR SHIELD, ASSEMBLY

Specifications

Attachment (Plastic Shield To Ring): Epon 934 Adhesive
Material (Ring): Aluminum Alloy
Material (Shield): Plastic
Body Outer Diameter (Ring): 5.010″ Nominal
First Step Length (Ring): 1.130″
First Step Outer Diameter (Ring): 5.500″ – 5.502″
Flange Outer Diameter (Ring): 6.000″ Nominal
Flange Side inner Diameter (Ring, Rounded Radius): 0.987″
Flange Width (Ring): 0.080″ Nominal
Inner Diameter (Plastic Shield): 5.500″ Nominal
Outer Diameter (Plastic Shield): 6.339″ Nominal
Overall Length (Plastic Shield): 0.450″ Nominal
Overall Length: 1.950″ Nominal
Right Side inner Diameter (Ring): 4.753″ – 4.756″
Length (Body): 0.740″

Part Number: 204-012-116-003
Unpunctuated: 204012116003
